Nashville Data Center

TierPoint’s Nashville data center offers complete solutions for enterprise customers. Leveraging our core nationwide IP network, our data center offers cloud services, managed services, business continuity and more.

Statistics show the majority of businesses who do not have business continuity, disaster recovery and IT backup plans in place eventually fail after they experience a disaster. The data center is audited under SSAE 18 Type 2 SOC 2, PCI-DSS1*, GLBA and HIPAA standards annually. ITAR and EU-US Privacy Shield registered. This facility is designed to ensure your critical IT systems, applications and data are safe from tornadoes, hurricanes, earthquakes, fires, floods and other disasters – natural or otherwise.

*Please see Security & Compliance section below for details

Highlights

  • Tennessee’s only Tier III data center, certified for both design and construction by the Uptime Institute
  • The state’s only purpose-built data center:
    – Currently 54,000 sq. ft. with16,000 sq. ft. of
    raised floor
    – Additional future facility expansions in
    increments ranging from I0,000-I5,000 sq. ft.
  • LEED Gold Certified
  • Generation 3 multi-tenant cloud pods, private clouds and hybrid solutions
  • VESDA — Very Early Smoke Detection Apparatus
  • Hardened data center rated for I49 MPH winds, class 4 hurricanes and EF3 tornados
  • Outside of major flood zones at approximately 700 feet above sea level

Facility

  • 54,000 sq. ft. facility with I6,000 sq. ft. of raised floor data center space
  • 24x7x365 access
  • Secured customer cages and cabinets available
  • Robust network operations center (NOC)
  • VESDA smoke detection system
  • Double interlock dry pipe pre-action sprinkler system (zoned)
  • Hardened data center rated for I49 MPH winds, class 4 hurricanes and EF3 tornados
  • Outside of major flood zones, approximately 700 feet above sea level
  • N+1 cooling
  • Hydraulic lift system for loading and unloading

Security

  • 24x7x365 on-site personnel
  • Card access system
  • Electronic verification by TierPoint personnel
  • Biometric identity access system
  • SSAE 18 Type 2 SOC 2, PCI-DSS1*, GLBA and HIPAA standards annually. ITAR and EU-US Privacy Shield registered
  • Video surveillance with capture to DVR
  • Mantraps

*1PCI-DSS – Certification on PCI-DSS Requirement 9 & 12 (Physical Security and Information Security Policies) on data center (colocation) services. Colocation provides secure space, power,
and environmental controls for merchants and service providers, some of which fall under PCI compliance. No logical access to any customer systems that may contain cardholder data.

Power

  • Tier 3 modular design for easy capacity expansion
  • Fully 2N A-side and B-side power distribution design
  • Tier 3 certified for design and construction by the Uptime Institute
  • 5,000kVA of utility capacity expandable to I2,000kVA
  • Four redundant 2,000kW Cummins generators each with 4,200 gallons of fuel storage
  • 2N redundant 2,400kW high-efficiency UPS System
  • 16 300kVA power distribution units (PDU) with branch circuit monitoring

Network

  • Carrier neutral, high availability and resilient Internet connectivity
  • Multiple feeds to each building from separate paths
  • Redundant IP bandwidth available with I0GB connectivity
  • Cross connections of standard media types to connect customers to the carrier of their choice

Connectivity

On-Net Carriers

  • AT&T
  • Comcast
  • Level 3
  • TW Telecom
  • Windstream
  • XO Communications
  • Zayo Group

Franklin Location

311 Eddy Lane
Franklin, TN 37064
(877) 859-8437
